Pharmaceutical Alu

Basic Info.

Model NO.	DPP-260
Customized	Customized
Condition	New
Warranty	1 Year
After-sales Service	Engineers Available to Service Machinery Overseas
Max Forming Area and Depth	25018026mm
Cutting Frequency	6-70 Times/Min
Ptp Aluminum Foil	0.02-0.035*260mm
Dialysis Paper	50-100g*260mm
PVC Rigid Sheet	0.25-0.5*260mm
Packing for	for Solid Packing
Principle	Flat Plate Thermoforming and Heat Sealing
Packing Material	PVC Rigid Sheet;Ptp Aluminum Foil;Dialysis Paper
Use	Small Pharmacy Factory
Machine Type	Blister Packing Machine
Transport Package	Export Standard Package
Specification	39007301600mm
Trademark	RoyalPharma
Origin	Shanghai, China
HS Code	8422400000
Production Capacity	20set/Month

Product Description

DPP-260 Flat Plate Automatic Tablet Capsule Blister Packing MachineInstruction and features:
This product is a new packing machine designed by our company; It has reached domestic leading level. It is suitable for capsule, tablet, big honey pill, candy, liquid, paste, syringe as well as irregular shape Al-plastic, paper-plastic composite and Al-Al sealing packing in pharmacy, healthcare, food, cosmetics, medical equipment industry etc. This machine adopts micro-computer PLC, frequency converter, touch panel operation, high automation; It is an ideal blister packing equipment. The product passed the provincial science and technology appraisal.Traction drive by servo motor (traction by precision lead screw or rubber press roller), with precise synchronization. The length of travel range can be set in man-machine interface.Equipped with eye marking system, the background of printed pattern is uniform and looks pleasant Available for Al-Plastic (hot forming) and Al-Al (cold forming), only change mould and feeder for Al-Al packing.Various types of feeder solve the difficulty for irregular shape products packing.Five stations forming, heat-sealing, batch number embossing, avulsion Line impressing and cutting etc all adopt gear mandrel orientation, each can move freely in the mandrel when rotate the hand wheel, easy to adjust and accurately.Newly mould orientation device speed up the mould changing requirement.Equipped with plexiglass cover: The operation area is isolated with transmission organ, avoids pollution, easy for clean.Apply online detection and ejection system, and the camera detection system can be chosen for optionProduct Prameters:

Cutting frequency (times/min)	Al-plastic packing:
	precision lead screw< =60,
	rubber press roller< =70,
	Al-Al packing< =40
Production capacity(pcs/h)	Al-plastic: < =300000; Al-Al: < =100000
Max. Forming areas and depth (mm)	Al-plastic: 25018026; Al-Al: 25018014
Travel Range (mm)	0-180 (precision lead screw);
Travel Range (mm)	0-220 (rubber press roller)
Standard Plate (mm)	80*57 (Can be manufactured as user' s requirements)
Air pressure (Mpa)	0.4-0.6
Air supply	≥ 0.36m3/min
Total power	380V/220V 50Hz 6.2kw
Main motor power (kw)	1.5
PVC rigid sheet (mm)	0.25-0.5*260
PTP aluminum foil (mm)	0.02-0.035*260
Dialysis paper (mm)	50-100g*250
Mould cooling	Tap water or circulating water
Overall dimensions (mm)	39007301600 (LWH)
Weight (kg)	1600
